Technical Data
Specification Table.
Technical Data
PRODUCT SPECIFICATION:
- Single CT Sensing
- Available 8 or 12 stages
- Automatic Sensing of Capacitor bank Values
- Measurement Range of Power Factor : From 0.8 lag to 0.8 lead
- APFC147 Size:144(H)x144(W)mm
Specification Table.
1CT Sensing, 8 Stage, Size : 144 x 144mm [APFC147]
| Display Type | 7 Segment LED |
| Display Configuration | 1 Line 4 Digits to show Power Factor |
| Input Type | 2Ø-2 Wire, 1Ø-2 Wire |
| Frequency | 45-65 Hz |
| Measurement Range | Power Factor: 0.8 to -0.8 |
| CT Primary | 1/5A to 9999A (Programmable for any Value) |
| CT Secondary | 1 or 5 A (Programmable) |
| Accuracy | Power Factor: ±0.01 |
| Max Number of Steps | 8 |
| Communication Protocol | NA |
| Supply Voltage | 90 to 550V AC |
| Bezel Size | 144 x 144mm |
| Mounting Type | Panel Mount |
