Technical Data
Specification Table.
Technical Data
PRODUCT SPECIFICATION:
- 3CT Sensing
- In Built VAF meter
- Configurable up to 12 / 14 stages
- Configurable Alarm Settings
- RS485 MODBUSRTU Protocol
- Automatic Sensing of Capacitor bank Values
- Size:144(H)x144(W)mm
Specification Table.
Built in VAF, Dual Colour Backlight, RS485 Communication MODBUS RTU Protocol [APFC148]
| Display Type | LCD with Dual Colour Backlight |
| Display Configuration | 3 Lines of 4 Digits to Show Electrical Parameters |
| Input Type | 3Ø-4 Wire, 3Ø-3 Wire, 2Ø-2 Wire, 1Ø-2 Wire |
| Frequency | 45-65 Hz |
| CT Primary | 1/5A to 9999A (Programmable for any Value) |
| CT Secondary | 1 or 5 A (Programmable) |
| PT Primary | 100V to 500kV AC (Programmable for any Value) |
| PT Secondary | 100 to 500V AC (Programmable for any Value) |
| Accuracy | Power Factor:±0.01, Voltage (L-N/L-L), Current: ±0.5% of full scale, Frequency – For L-N>20V, For L-L>35V: ±0.1% of full scale, Power (kW,kVA,kVAr), Energy (kWh,kVAh,kVArh): Class 1, Temperature : ±3° of full scale |
| Max Number of Steps | 12/14* (FAN & ALARM Output Can be Used as 13th and 14th Step) |
| Communication Protocol | Modbus RTU (RS485 Interface) |
| Supply Voltage | 90 to 550V AC |
| Bezel Size | 144 x 144mm |
| Mounting Type | Panel Mount |
